For all 108, 109, 114, 115, 107, 116, 123, 126, 201, and 124 chassis from 1965 to 1995. I wrote this repair guide to show you how to properly remove your instrument cluster and replace worn or failing components. (NOTE: This is not a detailed manual on how to repair the components. In most cases it is best to just replace them with new or used units or send them out for overhaul.)
Product Details
If your dash lights are not working, if the odometer is not moving, if the tach or clock does not work, if oil is dripping out from under the dash, if your speedometer is making funny noises, then this guide will help you find the solutions. I even include some tips on what you can do if your engine instruments are jumping around. I can not guarantee success in fixing jumping gauges in all instances but it is worth trying some things outlined in the manual before you replace expensive instruments.
The PDF digital manual is 20 pages long and contains over 50 pictures with clear explanations. There are individual short sections covering each of the different chassis models mentioned above.
WARNING: 107 SL Owners: In most cases you will need to remove the steering wheel to get the instrument cluster out. This manual DOES NOT cover the removal of the steering wheel or the disconnect of the air bag on 1986 to 1989 models. You will need to refer to the factory manual for that information.
How to view this on-demand Manual:
Once you complete the purchase of this manual you will be able to download it immediately when you are logged in and on your personal account page (click on My Account). The PDFs will show up under My PDF Manuals. You will be allowed three downloads, so please save the file on your machine for backup.
Important note: This PDF may or may not contain all the information you will need to solve your specific problem. Please read the description carefully and make certain it applies to your particular Mercedes. If you are not certain please contact us first. Due to the nature PDF download manuals or instructions we can not issue a refund if you purchase in error or assume it contains information it does not. Please keep in mind that no follow-up technical support is implied or offered after purchase.
